ISUZU

Outboard C.V.Joint Car Engine AT/MT Year A
No. of
Outer
Teeth
B
Seal
Dia
mm
C
No. of
Inner
Teeth
D
Thread
F
Internal
Groove
G
Overall
Heibht
ABS
No. of
ABS
Teeth
YAC No. Model
D-MAX
IU-10 4×4       17 53 33 InnerM8/1.25 F1 208
ELF
IU-11 SV4       Inner20 52 20 - F1 117
FASTER RODEO
IU-09 2.2     88- 17 53 23 InnerM8/1.25 F2 208
I-MARK
GM-04 All Models 82AC  Exc.Turbo   85-89 22 50 22 20/1.0 F1 147.5
GM-07 All Models 82AC  Exc.Turbo   85-89 22 50 21 20/1.0 F2 147.5
IMPULSE
GM-14 All Models   MT 90-93 24 50 30 20/1.0 F2 144 42
TROOPER-PICKUP-RODEO
IU-01 1.2 TD C223T   84- 24 48 23 - F2 204.5
2.2  4ZD1 UBS16   87-
  4WD Models   81-87
IU-02 2.8 TD 4WD UBS55  4JBIT   87- 17 53 26 InnerM8/1.25 F1 215
2.8 TD 4WD UBS55  4JBITC   88-
IU-03 2.3 4WD   87-91 17 53 23 InnerM8/1.25 F2 202
IU-04 All Models   AT&MT 87-95 17 53 26 InnerM8/1.25 F2 215
IU-05 All Models   AT&MT 87-95 17 53 25 InnerM8/1.25 F2 214.5
IU-06         17 53 33 InnerM8/1.25 F1 214
IU-08 3.5     00- 17 53 33 InnerM8/1.25 F1 205
IU-09 All Models     89-91 17 53 23 InnerM8/1.25 F2 208
STYLUS-GEMINI
GM-11 1.6 SOHC AT&MT 90-93 22 50 21 20/1.0 F2 142.5
GM-12 1.6 SOHC AT&MT 90-93 22 50 22 20/1.0 F2 142.5

IU-07         17 53 25 InnerM8/1.25 F3 205
